JS Demystified 05 — Closure

A humble attempt to demystify tricky concepts in JavaScript

JS Demystified Series

• 01 — Variable Hoisting
• 02 — Function Hoisting
• 03 — Scope
• 04 — Execution Context
• 05 — Closure: this post

Intro

I hope you enjoyed my last post in the series, where we looked at execution context in great detail.

Now, it’s time to talk about closures.

If you are not comfortable with topics listed below, I recommend you to take a moment to refresh your knowledge there.

01 — Variable Hoisting
02 — Function Hoisting
03 — Scope
04 — Execution Context

Are you ready?

Great, let’s get to it.

Quiz — Test Your Knowledge

What would the below code print out?

Closure quiz

The answer is Hello John.

Yes, even though we altered the value of name to 'Sam' before we invoked sayHello. It’s as if, the value of name was captured before it was reassigned to 'Sam'.

That is exactly what happened — this is closure in action.

Scope Chain — Take 2

Before we can talk more about closures, we need to take a step back and have a closer look at a scope chain, which I introduced to you in my last post.

Here’s an excerpt:

In addition to its own scope, every execution context has a reference to its outer scopes (if any), all the way up to the global scope. This chain of reference is what we call a scope chain.

JS Demystified 04 — Execution Context

In summary, for a given scope, a scope chain is created during the creation of a new execution context upon a function call, and it is a reference to variables that belong to outer scopes.

So we know what it is and when it’s created, but we still don’t exactly understand how a scope chain is created. For this, we need to introduce a new player to the story — [[scope]] property of a function.

[[scope]] Property

Every function, on creation, is assigned an internal property [[scope]].

That means, when an execution context encounters a function creation (by function declaration or function expression), the function is given a [[scope]] property. The value of the [[scope]] property is the scope chain of the execution context, in which the function is created.

Then, the moment the function is invoked, a new execution context is created for that function call, and a scope chain is created at this time, collecting reference to all the locally scoped variables.

In addition, the scope chain inherits the the value of the [[scope]] of the function invoked as a separate property. This is how a scope chain holds the reference to outer variables.

Remember, the [[scope]] property is assigned to a function when it is created, not when it’s invoked. Then, when the function is invoked, the value of [[scope]] becomes the reference to the other variable within the scope chain of the new execution context.

Okay, I’ve been talking a lot!

Let’s use below snippet to demonstrate.

• line 5: The global execution context encounters a function declaration of the outer function. Since the scope chain of the global execution context contains only the global object { a: 'global' }, the outer function is assigned an internal [[scope]] property: { a: 'global' }.
• line 30: The function outer is invoked, a new execution context is created. The scope chain creates a reference to the locally scoped variable b whose initial value is undefined (remember hoisting?). In addition, the scope chain inherits the value of [[scope]] as a reference to its outer scopes.
• line 12: The execution context encounters a function declaration of the inner function. The current scope chain contains references to locally scoped b, as well as to the outer variables, so it’d look like this: { b: 'outer', outerScope: { a: 'global' }, which now gets assigned to the inner function’s [[scope]] property.
• line 27: The function inner is invoked and — same story — a new execution context is created. The scope chain collects reference to locally scoped c. In addition, it inherits the value of [[scope]], i.e. { b: 'outer', outerScope: { a: 'global' }, as a reference to the outer scope.
• line 22–24: When the time the JavaScript engine reaches the console.logs, the current scope chain contains { c: 'inner', outerScope: { b: 'outer', outerScope: { a: 'global' } }. Therefore we have access to all a, b, and c.

Got it?

Now we understand:

1. What is the [[scope]] property of a function.
2. When it is created.
3. How it relates to a scope chain of the current and child execution context.

We’re finally ready to look at what exactly a closure is.

Closure

Let’s think about a scenario, deriving form our example above.

What if you want to invoke the inner function later in the execution, rather than immediately calling it within the outer function? What would console.logs within the inner function would print out?

We get the exactly same result as before.

• line 15: Even though the execution context of a function call outer() was removed after returning, the returned inner function (which was assigned to a variable innerFunc) retained its [[scope]] property { b: 'outer', outerScope: { a: 'global' }.
• line 17: Upon invocation of innerFunc, the scope chain of the new execution context inherited the [[scope]] property as the reference to outer scopes. Therefore, a and b were both available to access from this execution context.

In fact, this reference to the outer variables, which is

1. created on function creation
2. available even after the outer execution context is removed

is what we call a closure.

By Reference, Not By Value

It is important to note that a closure captures the reference to the outer variables, not their values per se. All it remembers is where to find variables, which might be pointing to different values at different times.

In other words, the value of the variables inside a closure can be modified.

Consider a case where we change the value of the global variable a, before we invoke the returned function.

• line 15: Assigned the returned function to innerFunc.
• line 17: Modified the value of a to GLOBAL.
• line 19: At the time of invocation of innerFunc, the value of a is GLOBAL.
• line 9: Therefore when it was accessed a it gave us GLOBAL.

Variable Lookups

But wait — you might think — why the heck was name 'John' in the very first example?

If we follow the by reference principle we just discussed, surely name points to 'Sam' because we reassigned it before we called the returned function.

You’re right, but there’s a slight yet significant detail we’re missing.

Here, name is passed to the greet function as a parameter, which behaves as a local variable for the execution context of a function call.

• line 5: The global execution context encounters a function creation. greet’s [[scope]] property is assigned the current scope chain { name: 'John' }.
• line 17: greet is invoked with a parameter name, which currently points to 'John', and the returned function is assigned to sayHello.
• line 8: The parameter name is treated as a locally scoped variable of the newly crated execution context. Further, the scope chain inherits the reference to outer variables stored in [[scope]] property.
• line 9: The current execution context encounters a function creation and its scope chain is { name: 'John', outerScope: { name: 'John' } }. This becomes the [[scope]] property of the returned function.
• line 19: The global name is reassigned 'Sam'.
• line 22: sayHello is invoked, the new execution context in created, and the scope chain inherits the [[scope]] property of the invoked function. Globally scoped name is now pointing to 'Sam', whereas locally scoped name still points to 'John'.

Variable lookups always starts from the local scope. Only when the JavaScript engine can’t find a variable within a local scope, does it go up one level in the scope chain to see if it’s defined there, and so on.

Therefore, when name is access at line 13, the engine finds it in the local scope, the console.log prints out Hello John.

Further Reading

Here are a few of the sources I found useful and got some inspirations from:

• http://jibbering.com/faq/notes/closures/
• https://stackoverflow.com/questions/500431/what-is-the-scope-of-variables-in-javascript
• https://www.ecma-international.org/ecma-262/8.0/index.html

Wrap-up

Alright, that’s it.

A closure is often considered an elephant in the room which no one wants to acknowledge and talk about. Hopefully I’ve managed to demystify it, by explaining what’s happening under the hood.

Please post any feedback, questions, or requests for topics. I would also appreciate 👏 if you like the post, so others can find this article too.

Thanks, and see you next time :)
